What is Hopper Slide Valves Gates?

Slide valves, gates, and fittings are the connection components that transform a set of individual machines into a complete operational production system for hopper dryers, solids & bulk handling.

The mechanical slide valve for hopper Slide Valves Gates comes with a bearing type or without a bearing type your choice.

The Hopper Slide Valves Gates are supplied by DGMF Mold Clamps Co., Ltd, the mold clamps Manufacturer in China that also provides injection mold componentsdie press componentsmachine tools, and fasteners for your best choice.

The Hopper Slide Valves Gates Specifications

Hopper Slide Valves Gates Model: DGMF-Mold-Clamps-SV102

Specification
Installation size(mm)
25-50 (KG)
General-purpose Slide Plate (mm)
75-100 (KG)
General-purpose Slide Plate (mm)
150-200 (KG)
General-purpose Slide Plate (mm)
Plate length550600900
Plate thickness162025
Plate width120140150
Width of the moving cover140170190
Diameter of the feed opening506275
Sliding plate height97108108
Sliding plate base140170190
Base hole position60-12475-16580-185
Moving cover center hole positionLength 100 Width 90Length 110 Width 110Length 130 Width 130
550mm 20-50KG Hopper Slide Valve With Bearing - DGMF Mold Clamps Co., Ltd
550mm 20-50KG Hopper Slide Valve With Bearing – DGMF Mold Clamps Co., Ltd



550mm 20-50KG Manual Slide Gates for Hoppers Without Bearing - DGMF Mold Clamps Co., Ltd
550mm 20-50KG Manual Slide Gates for Hoppers Without Bearing – DGMF Mold Clamps Co., Ltd



600mm 75-100KG Hopper Slide Valve With Bearing - DGMF Mold Clamps Co., Ltd
600mm 75-100KG Hopper Slide Valve With Bearing – DGMF Mold Clamps Co., Ltd



600mm 75-100KG Manual Slide Gate Valve Without Bearing - DGMF Mold Clamps Co., Ltd
600mm 75-100KG Manual Slide Gate Valve Without Bearing – DGMF Mold Clamps Co., Ltd



700mm 20-50KG Hopper Slide Valve With Bearing - DGMF Mold Clamps Co., Ltd
700mm 20-50KG Hopper Slide Valve With Bearing – DGMF Mold Clamps Co., Ltd



700mm 20-50KG Manual Slide Valve for Hopper Without Bearing - DGMF Mold Clamps Co., Ltd
700mm 20-50KG Manual Slide Valve for Hopper Without Bearing – DGMF Mold Clamps Co., Ltd



750mm 75-100KG Hopper Slide Valve With Bearing - DGMF Mold Clamps Co., Ltd
750mm 75-100KG Hopper Slide Valve With Bearing – DGMF Mold Clamps Co., Ltd



750mm 75-100KG Hopper Valve Slide Valve Without Bearing - DGMF Mold Clamps Co., Ltd
750mm 75-100KG Hopper Valve Slide Valve Without Bearing – DGMF Mold Clamps Co., Ltd



900mm 150-200KG Hopper Slide Valve With Bearing - DGMF Mold Clamps Co., Ltd
900mm 150-200KG Hopper Slide Valve With Bearing – DGMF Mold Clamps Co., Ltd



Hopper Slide Valves Gates Product Features

Stable

Uniform inflation

Small fuselage

Durable

Mechanical slide gate valve for hopper - DGMF Mold Clamps Co., Ltd
Mechanical slide gate valve for hopper – DGMF Mold Clamps Co., Ltd



Injection molding mechanical slide valve for hopper - DGMF Mold Clamps Co., Ltd
Injection molding mechanical slide valve for hopper – DGMF Mold Clamps Co., Ltd



How Does Feed Hopper Work On Hopper Slide Valves Gate?
